4-in-1 Business-Ink Multifunktionsgerät mit LAN/WLAN, 250 Blatt Papierkassette und DIN A3 Druckfunktion
MFCJ5320DWG1
MFCJ5320DWG1
Druckertyp | Farbe |
---|---|
Druckerfunktionen | Drucken, Kopieren und Scannen, Faxen |
Display | Farb-Touchscreen |
Displaygröße | 6.8cm touchscreen |
Max. Papierformat | A3 |
Arbeitsspeicher | 128MB |
Produkttyp | Tintenstrahldrucker |
Creative Center | Ja |
---|---|
Note Scan | Ja |
Konnektivität | LAN, WLAN |
---|---|
Lokale Schnittstelle | Hi-Speed USB 2.0 |
Wi-Fi Direct | Yes |
LAN-Schnittstelle | Ethernet 10/100BASE-TX |
WLAN-Schnittstelle | 802.11b/g/n |
Unterstützt | AirPrint, Google Cloud Print, iPrint&Scan, Wi-Fi Direct |
---|
Auflösung | Up to 1,200 x 1,200dpi (colour and mono) |
---|---|
Geschwindigkeit | 12ipm (mono) and 9ipm (colour) |
Abmessungen mit Verpackung | 589 (W) x 368 (D) x 362 (H)mm |
---|---|
Gewicht mit Verpackung | 14.7 kg |
Abmessungen ohne Verpackung | 490 (W) x 290 (D) x 240 (H)mm |
Gewicht ohne Verpackung | 10.8 kg |
Schalldruckpegel | 50dB (A) (Maximum) |
---|---|
Umwelt-Prüfsiegel „Blauer Engel“ | Ja |
Energy Star environmental accreditation | Ja |
Umwelt-Prüfsiegel „Nordic Swan“ | Ja |
Leistungsaufnahme | Operating: 32W, Ready Mode: 5.5W, Sleep Mode: 1.8W, Off: 0.04W |
Faxmodem | 14.4 Kbit/s |
---|---|
Internet-Fax | Yes (Download from http://support.brother.com) |
PC-Fax | Send and receive |
Inhalt | Fax line cord, Power supply cord, Product safety guide, Software disc, Ink Cartridges, User guide, Warranty card, Quick setup guide |
---|
Medienformate | Standard Tray /Manual Feed Slot: A3, A4, A5, A6, LTR, EXE, LGR, LGL, Photo, Indexcard, Photo-L, Photo-2L, Com-10, DL Envelope, Monarch, C5 |
---|---|
Mediengrammatur | Standard Tray: Plain, Inkjet, Glossy(cast/resin) 64-220g/m2. Manual Feed Slot:Plain, Inkjet, Glossy(cast/resin) 64-220g/m2. Auto Duplex: Plain 64-120g/m2. |
LAN Netzwerk | Ethernet 10/100BASE-TX |
---|---|
Sicherheit für LAN-Netzwerke | APOP, SMTP-AUTH, SSL/TLS(SMTP, POP, IMAP4) |
Wireless-Netzwerk | 802.11b/g/n |
Wireless-Netzwerksicherheit | WEP 64/128bit, WPA-PSK(TKIP/AES), WPA2-PSK(AES) |
Gelieferte Software - Mac | Brother ControlCenter2, NewSoft® Presto!® PageManager9 |
---|---|
Gelieferte Software - Windows | Brother ControlCenter4, Nuance® Paperport® 12 SE with OCR |
Betriebssysteme | Windows® 7 (32bit(x86) & 64bit(x64) editions), Windows® 8 (32bit(x86) & 64bit(x64) editions), Windows Vista® (32bit(x86) & 64bit(x64) editions), Windows® XP Professional (32bit(x86) & 64bit(x64) editions), Windows® XP Home, Windows Server® 2003 & 2008 (32bit(x86) & 64bit(x64) editions),Windows Server® 2008 R2 & 2012 (64bit(x64) edition), OS X v10.7.5/10.8.x/ 10.9.x |
Papierzuführung | 250 sheet standard paper tray, 1 Sheet Manual Feed Slot, 35 sheet automatic document feeder (ADF) |
---|---|
Papierausgabe | 50 sheets |
Druckauflösung | Up to 6,000 x 1,200 dpi (Vertical x Horizontal) |
---|---|
Geschwindigkeit - Schnell-Modus | Up to 35ppm mono & 27ppm colour |
Geschwindigkeit - vergleichbar mit Lasergeschwindigkeit | 22ipm mono & 20ipm colour |
Automatischer beidseitiger Druck | Ja |
Tröpfchengrösse | 1.5 Pikoliter |
Scanauflösung | Optical: From Flatbed Up to 1,200 x 2,400dpi. From ADF 2,400 x 1,200dpi. Interpolated: Up to 19,200 x 19,200dpi |
---|---|
Scannen an | Email, OCR, Image, File, USB Flash Memory Drive, FTP, Network*, Email Server**, Web Services *Windows® only, **Optional free download available from http://support.brother.com |
Scangeschwindigkeit | From 3.37 seconds mono & colour (A4 size, 100 x 100dpi) |
Unterstützt | AirPrint, b-guard, Box, BR-Docs (US/UK/GER/FRA only), Cortado Cloud Print, Dropbox, Evernote, Evernote Business, Google Cloud Print, Google Drive, iPrint&Scan, Managed Print Services, OneDrive, OneNote |
---|
Brother-Papier | BP71GA3: A3 glossy photo paper, 20 sheets, BP71GLA: A4 glossy photo paper, 20 sheets, BP71GLP: 10x15 cm glossy photo paper, 20 / 50 sheets, BP60MA: A4 Matte inkjet paper, 25 sheets, BP60PA: A4 inkjet paper, 250 sheet |
---|---|
Jumbo-Tintenpatronen | Black: LC229XL BK - Approx 2,400 A4 pages Cyan / Magenta / Yellow: LC225XL C/M/Y - Approx 1,200 A4 pages. Cartridge yield is declared in accordance with ISO/IEC 24711 |
Standard-Tintenpatronen | Black: LC223BK - Approx 550 A4 pages, Cyan / Magenta / Yellow: LC223C/M/Y - Approx 550 A4 pages. Cartridge yield is declared in accordance with ISO/IEC 24711 |
Drucken aus | PictBridge, USB Flash Memory Drive |
---|
Garantie | Two Year Back to Base Warranty |
---|
Laden Sie sich aktuelle Treiber und Software für Ihre Brother Produkte herunter.
Downloads anzeigenHier finden Sie alle Antworten auf häufig gestellte Fragen und Problemlösungen.
FAQ anzeigenLaden Sie Handbücher und Installationsanleitungen herunter.
Handbücher anzeigen"Der Brother MFC-J5320DW druckt sehr günstig. Selbst wer viel in Farbe druckt, wird dabei nicht arm. In Schwarz-Weiß druckt das Multifunktionsgerät sehr ordentlich und flott, in Farbe richtig gut, dafür aber deutlich langsamer. Pfiffig: Der Vorlageneinzug lässt sich einklappen, wenn er nicht gebraucht wird."
